Black stone-filled heater set into pale wood panelling beside a glowing red infrared panel

[ Project ]

Ulus Private Property

Istanbul · Türkiye

Sauna Dekor Spa Solutions — designing, manufacturing and installing saunas, steam rooms, hammams and pools since 1987, in our own facility in İkitelli OSB, Istanbul.

A private sauna built into a hillside residence at Ulus, Istanbul — glazing-led design, heat load, ventilation strategy and cabin build-up explained.

  • Sauna

Project summary

What we delivered

  • Rooms: Sauna
  • Where and when: Istanbul · Türkiye, 2019
  • In short: A private sauna built into a hillside residence at Ulus, Istanbul — glazing-led design, heat load, ventilation strategy and cabin build-up explained.

[ 4 photos ]

From the project

Infrared sauna
Infrared sauna
Infrared sauna

[ The build ]

01

Overview

Sauna Dekor builds thermal areas end to end — design, manufacture, installation and commissioning under one contract. The company started in 1987, is in its 40th year, manufactures in İkitelli, Istanbul, and has completed projects in 41+ countries.

This project is a private sauna inside a residence at Ulus, on the Bosphorus slope in Istanbul. The owner is not named; the page records the district, the property type and the work. The zone listed for the project is a sauna.

02

Scope of work

A dry-heat cabin for a private house on a steep site: the insulated cabin structure,linings and benching, heater and control, glazing, lighting, and the ventilation and electricalinterfaces. Manufactured and dry-assembled in our Istanbul workshop, then numbered, delivered and installed.

03

Designing a cabin around a view

On a hillside site the reason the room exists is usually the outlook, and that pushes the design toward glass. Glass is the most expensive surface in a sauna thermally: it is continuous, poorly insulated compared with a built-up timber wall, and it radiates coolness onto whoever sits opposite it. Three decisions follow. The heater is sized with a real addition for the glazed area rather than from volume alone. The benches are positioned so nobody sits directly against the cold face, which is what makes a glazed cabin feel draughty even when the air temperature is correct. And the glazing itself is specified as a sauna component — toughened,correctly gasketed, with a door that seals without binding as the frame warms. Seesauna designs for luxury homes and sauna.

04

Heat load and electrical supply

General practice sizes a domestic cabin at roughly a kilowatt of stone-heater output percubic metre of volume, with additions for glazing and for masonry surfaces inside the envelope.The other half of the calculation is the house: a heater needs a dedicated circuit and, above a modest rating, a three-phase supply. In an existing residence that available supply is often what sets the practical maximum cabin size, so it is confirmed before the cabin is designed rather than after the joinery has been drawn. Oursauna heater types page sets out the classes.

05

Ventilation, vapour barrier and build-up

Air is introduced low, near or under the heater, and taken out low on the opposite side, soit crosses the bathers rather than short-circuiting to the ceiling; the extract is ducted somewhere that can accept warm moist air. The cabin itself is an insulated box: insulation, a continuous foil vapour barrier with taped laps, a ventilated cavity, then the lining. That barrier keeps the moisture a sauna generates out of the fabric of the house. Linings and benching are kiln-dried, low-resin timber with concealed fixings, and bench tops lift out for cleaning. More at sauna ventilation.

06

What we solved on site

Steep-site houses in Istanbul are built in levels, and the room a sauna goes into is often the one with the least floor-to-ceiling height and the most awkward access. We fixed thecabin’s internal height first — because the useful heat is in the top third of the room —worked the duct routes around it, and set bench levels last. The cabin was dry-assembled in ourIstanbul workshop, dismantled into pieces that would pass the access route, and numbered for reassembly. Seeprivate spa.

07

Frequently asked questions

Why can a glazed sauna feel cold even at the right temperature?

Because a large glass surface radiates coolness onto whoever sits opposite it. Benches are positioned so nobody sits directly against the cold face, and the heater is sized with a real addition for the glazed area.

Is sauna glazing a standard glass product?

No. It is specified as a sauna component — toughened, correctly gasketed, with a door that seals without binding as the frame warms through a session.

What sets the maximum cabin size in an existing house?

Usually the electrical supply. A heater needs a dedicated circuit and, above a modest rating, three phase, so the supply is confirmed before the cabin is designed.

How do you install in a house with awkward access?

By dry-assembling and checking the cabin in the workshop, then dismantling it into pieces that pass the access route and numbering them for reassembly, so nothing has to be cut on site.

Sauna Dekor’s own certification is TS EN ISO 9001:2015 quality management, covering sauna and spa product manufacturing and after-sales service. The equipment we install carries CE / EN 60335, TÜV, GS, GREENGUARD Gold, FSC and VDI 6022 certification from its own manufacturers — EOS, Sentiotec and Condair among them.
